MBS Series Rod Mill: High Performance Rod Mill for Sale
Working Principle
Rod mill is an asynchronous motor through the reducer and pinion gear connection, directly drive the surrounding gear to decelerate and rotate, drive the rotary part to rotate, the cylinder is equipped with the appropriate grinding medium - steel rod, grinding medium under the action of centrifugal force and friction, the material to be ground continuously from the feeding part into the cylinder, is crushed by the moving grinding medium. And through the power of overflow and continuous feeding, the product is discharged from the machine to carry out the next process.
Characteristic and feature of MBS series rod mill:
(1) Power saving
Compared with the older equipment, the power saving is more than 40%. The particle size of the product is more uniform, and the coarse particles and slime are less. Compared with the particle size characteristics of the products of the rod mill and the ball mill, the product size characteristics of the open-circuit rod mill are almost the same as that of the closed-circuit ball mill.
(2) Uniform discharge and high yield
The use of advanced controllable inlet and outlet rod mill technology, combined with the actual user's grinding materials with appropriate grinding body, a change of the traditional ball mill surface contact to line contact, so that Huali brand sand making machine discharge particle size is more uniform, higher yield, suitable for different hardness (Mohs hardness 5.5~12) of the ore.
Technical Parameters Of Pe Series Jaw Crusher
| Model | Drum size (mm) | Rod weight(T) | Feeding size(mm) | Final product size(mm) | Capacity(T/h) | Power(Kw) |
| MBS-0930 | 900×3000 | 2.5 | ≤25 | 0-4 | 3-8 | 22 |
| MBS-1230 | 1200×3000 | 4.9 | ≤25 | 0-4 | 5-25 | 45 |
| MBS-1245 | 1200×4500 | 5.2 | ≤25 | 0-4 | 6-35 | 55 |
| MBS-1530 | 1500×3000 | 8.1 | ≤25 | 0-4 | 7-45 | 75 |
| MBS-1836 | 1800×3600 | 11.6 | ≤25 | 0-4 | 10-65 | 132 |
| MBS-2130 | 2100×3000 | 20.1 | ≤25 | 0-4 | 20-74 | 210 |
| MBS-2436 | 2400×4500 | 28.3 | ≤25 | 0-4 | 35-95 | 245 |
