X Series Ultra-fine Grinder - High Precision Grinding
Working Principle
In the grinding room, the grinding roll assembly is suspended on the grinding roll hanger through the cross arm shaft, and the grinding roll hanger is fixed connected with the main shaft and the shovel holder. The pressure spring is tightly pressed on the outer end of the grinding roll chamber by the tension rod, and the cross arm shaft is the fulcrum. The grinding roll is tightly pressed on the inner surface of the grinding ring by the pressure of the spring. The grinding roller rotates and rotates around its own axis while rolling in the grinding ring. The analytical machine drives the impeller of the analytical machine to rotate through the motor transmission device, and the analytical machine achieves the purpose of producing powder by adjusting the speed.
Technical parameters of X series ultra-fine grinder
| Model | Max feeding size (mm) | Final product size(micron) | Capacity(T/h) |
Speed of main mill
(R/min)
|
Main unit power(Kw) | Dimensions (L×W×H) (m) |
| X-95 | <30 | 20-125 | 1.8-4.6 | 130 | 79-85 | 7.1×7.9×7.9 |
| X-130 | <30 | 20-125 | 2.6-8.5 | 103 | 169-185 | 7.85×9.0×9.7 |
| X-160 | <30 | 20-125 | 4.5-13.5 | 82 | 290-314 | 12.5×9.3×10.3 |
| X-190 | <35 | 20-125 | 6.5-19.5 | 68 | 515-545 | 14.5×11.2×11.2 |
